Fix using either no.12 x 50mm BZP wood screws or 75mm x 4.0mm galvanised nails – for stainless straps stainless fixings must be used.

Packed in bundles of 20.

Fix using either no.12 x 50mm BZP wood screws or 75mm x 4.0mm galvanised nails – for stainless straps stainless fixings must be used.

Packed in bundles of 20.

Fix using either no. 12 x 50mm BZP wood screws or 75mm x 4.0mm galvanised nails – for stainless straps stainless fixings must be used.

Packed in bundles of 10.

Fix using either no. 12 x 50mm BZP wood screws or 75mm x 4.0mm galvanised nails – for stainless straps stainless fixings must be used.

Packed in bundles of 10.

The back plate of the hanger should be flat against the supporting masonry. Before any loads are applied there should be at least 600mm of cured brick/block work above the hanger. The end of the joist should then be flush against the back of the hanger and side web holes filled with 30mm x 3.75mm square twist nails. The above hangers are also available with a return flange (RJH) and as a straddle or double hanger (STJH) which allows for positive location of the hangers in-situ and a straight joist line where required. When ordering these styles of built in joist hangers please clearly state the masonry or steel work size they are fitting over as they are generally made to order.

Hangers per Box

All hangers 150mm deep and above are undersized by 10mm to allow for notching of ceiling joists for flush finishing of the plasterboard.

Fixing:

Fix using 30 x 74mm square twist nails in all available nail holes.

100 per box.

Overall height: 185mm

Fixing:

Fix using 30 x 3.75mm sqaure twist nails in all available nail holes.

100 per box.

Overall height: 270mm

Fixing:

Fix using 30 x 3.75mm square twist nails in all available nail holes.

50 per box.

Overall Height: 450mm long

Also available to order as 600mm long.

Fixing:

Fix using 30 x 3.75mm square twist nails in all available nail holes.

50 per box.

Fixing:

Fix using 30 x 3.75mm square twist nails in all available nail holes.

250 per box.

Fixing:

Fix using 30 x 3.75mm square twist nails in all available nail holes.

Fixing:

Fix using nails in all available holes or bolts.

Note: To select the correct size of hanger required multiply the timber depth being fitted x 2 then add the timber width. The correct MH size will be smaller or equal to the result ie for a 50mm for 200mm joist the sum = 450MM so that an MH380/50 will be the correct size to use (MH500/50 would leave the hanger above the joist top 25mm each leg).

Fixing:

Fixing:

Fix using 30 x 3.75mm square twist nails in all available nail holes.

Fixing:

Fix using 30 x 3.75mm square twist nails in all available holes.

(Also available Type A and Type B framings anchors L and R)

Fixing:

Fix using nails, bolts or screws.

Also available as flat plates.

Fixing:

Fix plates on either side of the timber joint. Fix using 30 x 3.75mm square twist nails in all available nail holes.

V55 Nail Plates per Box

Fixing:

Use with SPW Square Plate Washers.

Other sizes and single sided Connectors also available.

Other Timber Connectors:

We can also offer to order shear plate plate and split ring connectors plus the grooving tool necessary for fixing these where more heavy duty fixing is necessary.

Sizes:

67mm and 102mm Shear Plate Connectors

63mm and 102mm Split Ring Connectors.

Fixing:

Fix using nails, bolts or screws.

Fixing:

Fix using nails, bolts or screws.

Fixing:

Fix using 30mm x 3.75mm square twist nails.

Use all timber facing nail holes.

Minimum timber depth of 150mm.

Ensure the timbers project a minimum of 50mm beyond the edge of the angle plates.

Fixing:

Fixing:

Place sole plate on top and secure via upstand with square twist nails.

Fixing:

Fix using nails or screws.

Also available – 3mm and 5mm thick and as Baby Hip Irons for porches etc.

Baby Hip Iron size – 200 x 95 x 25 x 3mm

Fixing:

Stainless steel nails or staples should be used for fixing the eaves vent mesh.
